整機功能介紹
PerformanceCharacteristicsofTheWholeMachine
前緣吸附送紙，風量可調，主機變頻控制。
PLC電腦相位電動調整，各連接部氣動鎖定，電動分合，
精磨齒輪，齒輪潤滑采用噴淋式循環潤滑，免鍵結構鎖緊，
套色準確，印刷圖案精美。
使用和維修方便，自動化程度較高、高效率生產等。
The whole vacuum transfer design，full version printing with high definition.
Lead-edge suction feeding system，adjustable air volume，frequency convertor main motor.
Phase electric adjustment by PLC , connection unit locking by pneumatic,electrically control the separation and combination of machine.
Well grinded gear with spray lubrication system，Gears adopt keyless connection.
Chromatically multicolor printing accurately , printing effect beautiful.
Easy operation and convenient maintenance，high degree of automation，high effciency production.
技術參數(SPECIFCATIONS)
|
機型Model
|
TSG-2S-920
|
TSG-2S-1224
|
TSG-2S-1424
|
TSG-2S-1628
|
|
機械最高速度（張/分）
Max.MachineSpeed(pcs/minute)
|
280
|
230
|
200
|
180
|
|
最大進紙尺寸
Max.FeedingSize(mm)
|
900×2000
|
1200×2400
|
1400×2400
|
1600×2800
|
|
最大隔張送紙尺寸
JumpFeedMax.CardboardSize(mm)
|
1200×2000
|
1500×2400
|
1600×2400
|
1900×2800
|
|
最小進紙尺寸
Min.CardboardSize(mm)
|
300×600
|
365×600
|
400×600
|
450×600
|
|
最大有效印刷面積
Max.PrintingSize
|
900×1960
|
1200×2360
|
1400×2360
|
1600×2760
|
|
最小開槽間隙（正刀）
MinSlotterBladeSpace(sameside)(mm)
|
150×150×150×150
|
150×150×150×150
|
150×150×150×150
|
150×150×150×150
|
|
最小開槽間隙（反刀）
MinSlotterBladeSpace(againstside)(mm)
|
240×65×240×65
|
260×65×260×65
|
260×65×260×65
|
260×65×260×65
|
|
最大開槽深度
MaxSlottingDeep(mm)
|
250
|
300
|
350
|
400
|
注：產品的規格更改或機構改良，恕不另行通知。
Notes:Wewillnotgiveanotheradviceifwehavecorrectedthespecificationsoftheproductsorimprovedthemechanisms.
|
